Drawing a Site Plan
What is a Site Plan?
A site plan (sometimes called an allotment plan) is a drawing that shows the entire property and where proposed building works, demolition, or changes of use will take place.
Every Development Application (DA) must include a site plan, as required under the Environmental Planning and Assessment Act 1979.
The plan demonstrates:
The location of the property
The proposed works
Any existing structures on the land
Minimum Requirements
Under Schedule 1 of the Environmental Planning and Assessment Act 1979, Council cannot accept a DA without a compliant site plan.
At a minimum, your plan must show:
Property address
Date the plan was drawn
Length of each boundary and total site area
A north point
Setbacks of the proposed development and existing structures from each boundary
Existing vegetation and trees
Location and uses of current buildings on the property
Existing levels of the land in relation to buildings and roads
Location and uses of adjoining buildings
Examples
Example Shed, Carport or Garage Site Plan
Example Swimming Pool Site Plan
Example New Dwelling Site Plan
Standards and Quality
Your site plan must be clear, legible and easy to understand for both Council staff and members of the community viewing it during public notification. To meet this standard:
Always use a ruler and draw to scale (grid paper is recommended)
Ensure the plan is scanned (photos are not accepted)
Use dark, fine lines that can be read clearly on screen and in print (2B pencil or fine marker recommended)
Present information in a logical order
Review examples of good site plans before preparing your own
While applicants can prepare their own drawings, you may wish to engage a professional to ensure all requirements are met.
